NEWS Jan 16, 2012 - The new MITEQ model SYS2H1324N01X, Microwave Doubler, is ideally suited for local oscillator drive into wideband microwave mixers. This doubler utilizes three internally switchable bands; 13.9 to 16.9, 16.9 to 20.5, and 20.5 to 24.9 GHz. Internal high rejection filters allow for 60 dBc suppression of input related harmonics with respect to the output utilizing the potential of a high dynamic range mixer. The 13 dBm minimum output power is sufficient for driving most microwave mixers. This model also incorporates an internal voltage sequencing circuit to prevent damage from loss of negative voltage or improper sequencing.
Dec 28, 2011 - Airbus selects the LOR-220 for Final Assembly Lines in Toulouse
The LOR-220, made by Luciol, will be used especially in Final Assembly Lines of Airbus, to enable faster and more detailed tests of the optical fiber links. As the number of optical links increases in new airplanes, so is the need for suitable Test & Measurement equipment. The fact that Airbus has selected the LOR-220 is an encouraging sign for future applications in the civil aviation business, both for airlines and Maintenance and Repair Organisations. See the news from 16 September below for more information about LOR-220.
Dec 14, 2011 - Model AMF-6F-17702200-50-17P has been added to the MITEQ family of Ka-Band, single bias, coaxial line amplifiers. This LNA has over 35 dB of gain from 17.7 GHz to 22.0 GHz, in a housing that is only 0.72” long and 0.75” wide without the field replaceable K-connectors. Gain flatness is a maximum of 3.0 dB peak-to-peak, though typical is less than 2.0 dB. The AMF-6F-17702200-50-17P has a maximum noise figure of 5.0 dB in the full band, though the typical value is less than 3 dB. This unit has a P1dB minimum of +17 dBm and output IP3 of typically +25 dBm.
Nov 22, 2011 - Teledyne Relays introduces the first ever hermetically sealed LoopBack relay. The LoopBack relay (LB363/GLB363) combines the technology of two Teledyne RF300 Series relays and eliminates the need for external PCB traces in loop-back test applications. This innovation results in superior signal integrity and RF performance, while taking minimal board space. The relay is designed for digital signaling applications with excellent signal integrity up to 12 Gbps data rates. Additionally the relay has the low loss high frequency performance associated with the RF300 Series. The relay construction provides two internal paths: Through and AC Bypass. While the through path provides a loop-back path across high performance contact material the AC Bypass path adds a coupling capacitor across each loop-back path. The typical loop-back ATE application uses the Device Under Test (DUT) to test itself. In this method, the transmitter from the DUT is connected, through a loop back path, to the receiver of the DUT. The relay has a footprint of just 20.45mm x 9.52mm. with a choice of through hole or surface mount capability. For a data sheet check out our Downloads page.
Nov 4, 2011 - The introduction of the new Diamond Crocodile Fusion Alberino 1,25mm in 2009, based on the bi-adhesive concept, registered a certain success, since it facilitates the assembly process and allows to avoid the use of glue on the field, which in turn reduces the installation time.
The new Fusion Alberino further guarantees the same optical and mechanical performances as the
old Fusion Alberino, which however requires the use of glue during assembly. Thanks to the above mentioned advantages Diamond have decided a phase-out of the old Fusion Alberino within December 2012.
Oct 20, 2011 - Diamond releases the new Mini-AVIM Universal Flange for Multi-purpose Adapter System (MAS). The compact size and stable performance of the Diamond Mini-AVIM connector has led to the development of a new MAS Universal Flange based on this connector system. This new flange is
available alongside the existing FC version. The data sheet and P/N list have been updated to reflect the addition of this new flange to the Diamond product lineup. For MAS technical details and features see our Downloads page.
Sep 30, 2011 - Miteq desktop amplifier with digitally controlled variable gain. Frequency range of 0.1 to 40 GHz. Front panel digitally controlled. 15 dB gain control in 1 dB step. 100V to 240V AC operation. CE approved. For some more information download the specification from our Downloads page.
Sep 16, 2011 - Luciol introduces new options for the LOR product line. It now has an optional Optical Power Meter (OPM). The OPM is calibrated at several wavelengths: 670, 850, 1310 , 1550 and 1610 nm, and is suitable for both SMF and MMF. It can measure absolute power or use a reference as zero. It can also perform long term analysis, to monitor power fluctuations. The OPM is connected to a second optical port on the LOR front panel.
In addition, the LOR-220 with MMF at 670nm (for applications in commercial aviation) includes a Visual Fault Locator (VFL) option. The VFL generates a blinking red light, on the same output at the OTDR itself. Seeing this light at the end of the assembly under test, verifies the continuity of the assembly. In addition, it suppresses the possibility of errors, when checking cable assemblies with multiple fibers (you can be sure that you observe the fiber you wanted to analyse). The main advantage of this feature is that, once you see the blinking light at the end, you can immediately switch to the OTDR test, without exchanging connectors.
Sep 5, 2011 - MITEQ’s new Model JS3-18004000-40-15P is a state-of-the-art low-noise medium power amplifier with only 4 dB maximum noise figure and +15 dBm P1dB. This model has a gain of 32 dB minimum in a small hermetically sealed package with field replaceable K-connectors. MIL-883 screening is also available. Different options such as gain, noise figure and power output are also available.
Aug 18, 2011 - We have updated our homepage with some new functions.
On the frontpage and on the products page one can now access an Amplifier search page. On this page it is possible to search for Miteq amplifiers by specifying their characteristics. The search function will then present the models that best will fit your requirements. Remember though that Miteq are always willing to build custom models.
A new Download page has been added on which it is possible to download documents, articles etc. Our Toolbox has also been updated with a VSWR to RL converter.
Aug 3, 2011 - New data sheets for MITEQs AM-1695 available. Frequency range: 50-3000 MHz. Gain at 1500 MHz: 30dB. P1dB +19dBm. Noise figure 1.0dB. Contact MicroComp Nordic AB for a full specification.
July 6, 2011 - MITEQs new Model JS3-18002200-15-10P is a state of the art low noise Ka-band amplifier with only 1.5 dB maximum noise figure and 26 dB minimum gain in a small hermetically sealed Kovar chassis with field replaceable K-connectors. MIL-883 screening is also available. Different connector options are also available.
June 15, 2011 - Miteq Inc introduces a new addition, Model AMF-3F-20002600-68-20P-GC, to its family of rugged, single bias coaxial amplifiers. This amplifier has over 23 dB of gain from 20 GHz to 26 GHz, in a housing that is only 1” long and 0.83” wide without the field replaceable K-connectors. Application of +5V to the gain control pin decreases gain by 10 dB while maintaining flatness. Gain flatness is a maximum of ±1.5 dB, though typical is ±1 dB. The AMF-3F-20002600-68-20P-GC has a maximum noise figure of 6.8 dB in the full band, though the typical value is near 5 dB.
June 1, 2011 - Miteq Inc has now released the spring 2011 CD catalog. New additions to the catalog are the Amplifier Products Catalog and the Microwave Control Products. If you would like to receive a copy of the CD contact MicroComp Nordic AB.
May 20, 2011 - IntelliConnect is a new interesting partner to MicroComp Nordic AB. IntelliConnect is a UK based company with production in both UK and US. The company specialize in custom connector solutions. Among other things they have a new exciting range of waterproof IP68 connectors for harsh environments that is tested to 20m for four hours.
May 6, 2011 - Designed for OEM and scientific biophotonics applications, the ultra compact Calmar Mendocino FPL-05R laser head allows you to bring high power, ultrafast pulses directly to your sample in the smallest spaces for your live-cell imaging, multi-photon microscope, terahertz generation, etc. Average Power 500 mW, Wavelength 780 nm, Pulse Width 150 fs, Beam Quality TEM00 (M2 1.1), Repetition Rate 50 MHz, Ultra Compact Laser Head: 3 x 3 x 13.5 cm, read more.
April 21, 2011 - Both the Stanford Linear Accelerator Facility (SLAC) and Lawrence Berkeley National Laboratory (LBNL) have selected Calmar Laser’s Cazadero femtosecond fiber laser chirped pulse amplifier system for synchronized time-resolved experiments that reveal unique structural changes in novel material systems. The high energy output pulse of the fiber based system is used to induce a change in a material system of study, which is then interrogated at the atomic level by an X-ray pulse from the synchrotron. Read the full story |
